3x2 AH slurry pump,Centrifugal slurry pump warman

Sunbo HS slurry pump is equivalent to warman AH Slurry Pump,It is a single-stage, single-suction and horizontal heavy duty centrifugal slurry pump with a cantilever design, HS High Chrome Alloy Slurry Pumps are mainly used in solids containing applications. Depending on process conditions, equipment should be suitable for highly abrasive or corrosive liquids.

Parts in contacting with the medium are made of latest wear-resistance 27% chrome alloy white iron with hardness 62HRC over, which has an highly abrasive for maximum resistance to strong abrasive, coarse particle.

They are widely used for mining, coal, metallurgical, power, building material and other industrial departments. This series of pump is suitable for various liquids performance, which is the first select product for handling mine mill slurry and tailing slurry.

Basing on medium condition can choose different materials as A05, A07, A49 etc.

HS(R) SERIES CLEAR WATER PERFORMANCE
MODEL	OEM MODEL	MAX POWER	CAPACITY	HEAD	SPEED	MAX.Eff	NPSH
		(kw)	(m³/h)	H(m)	n(r/min)	%	(m)
25HS-B	1.5/1B-AH	15	12.6~28.8	6~68	1200~3800	40	2~4
25HSR-B	1.5/1B-AHR	15	10.8-25.2	7-52	1400-3400	35
40HS-B	2/1.5B-AH	15	32.4~72	6~58	1200~3200	45	3.5~8
50HS-C	3/2C-AH	30	39.6~86.4	12~64	1300~2700	55	4~6
75HS-C	4/3C-AH	30	86.4~198	9~52	1000~2200	71	4~6
75HS-D	4/3D-AH	60
100HS-D	6/4D-AH	60	162~360	12~56	800~1550	65	5~8
100HS-E	6/4E-AH	120
100HSR-D	6/4D-AHR	60	144~324	12~45	800~1350	65	3~5
100HSR-E	6/4E-AHR	120
150HS-E	8/6E-AH	120	360~828	10~61	500~1140	72	2~9
150HS-R	8/6R-AH	300
150HSR-E	8/6E-AHR	120	324~720	7~49	400~1000	65	5~10
150HSR-R	8/6R-AHR	300
200HS-ST	10/8ST-AH	560	612~1368	11~61	400~850	71	4~10
200HSR-ST	10/8ST-AHR	560	540~1188	7~45	300~650	80	2.5~7.5
250HS-ST	12/10ST-AH	560	936~1980	7~68	300~800	82	6
250HSR-ST	12/10ST-AHR	560	720~1620	13~14	300~500	79	3~8
300HS-ST	14/12ST-AH	560	1260~2772	13~63	300~600	77	3~10
300HSR-ST	14/12ST-AHR	560	1152~2520	11~63	250~550	79	4~10
350HS-TU	16/14TU-AH	1200	1368~3060	11~63	250~550	79	4~10
400HS-TU	18/16TU-AH	1200	2160~5054	8~66	200~500	80	4.5~9
450HS-TU	20/18TU-AH	1200	2520~5400	13~57	200~400	85	5~10

Features:

1.Replaceable wear-resistant metal or rubber liners and impellers, long service life time.

2. Easy to adjust the space between impeller and front liner and can be removed completely when maintaining.

3.Bearing assembly use grease lubrication.

4. Seal types: packing seal, expeller seal and mechanical seal.

5. Discharge direction can be installed at intervals of 45 degrees as request and oriented to any eight positions to suit applications.

6. Drive types: V belt drive, gear reducer drive, fluid coupling drive, and frequency conversion drive devices.

7. Wide application, good NPSH and high efficiency. The series pump can be installed in multistage to meet the delivery for long distance.
